赤峰福悅氧化鐵脫硫劑是以氧化鐵為主要活性組份，添加其它促進劑加工而成的高效氣體凈化劑。在20℃～100℃之間，對硫化氫有很高的脫除性能，對硫醇類有機硫和大部分氮氧化物也有一定脫除效果。氧化鐵脫硫劑是以活性Fe2O3為主要成份，并添加多種助劑制成。是一種適應性較強的新型高效的干法氣體常溫脫硫劑，能在常溫常壓或加壓條件下工作。對硫化氫有很高的脫除性能，對硫醇類有機硫和大部分氮氧化物也有一定脫除效果。

    赤峰福悅氧化鐵脫硫劑因其硫容大、價格低、可在常溫（20℃～100℃之間）下空氣再生等特點而深受用戶歡迎。使用上具有設備簡單、操作方便、硫容量大、凈化度高，適應性強等特點。

    氧化鐵脫硫劑因其硫容大、價格低、可在常溫下空氣再生等特點而深受用戶歡迎。但也存在著強度差、遇水粉化、脫硫精度不高(1ppm)等不足之處，影響了其工業應用。

    針對上述情況，我公司技術人員經過幾年潛心研究，開發了HYF系列新型氧化鐵脫硫劑，其特點是：

    1、脫硫精度高：進口H2SI1000ppm時，出口H2S 0.05ppm，比普通Fe2O3的脫硫精度(1ppm)高20倍；

    2、反應速度快：使用空速1000-20000h-1比普通Fe2O3要高3—6倍。

    3、工作（透穿）硫容大：在1和2的條件下，一次性精脫H2S硫容有O2時為15—20%，是普通Fe2O3脫硫劑的3—6倍。

    4、強度好、耐水性好。水煮2h或浸泡30天不粉化、強度不變。

    5、適用溫度范圍廣，5—90℃

    6、可在無O2或高CO2條件下應用。無氧時精脫H2S硫容12—15%。

    該脫硫劑適用天然氣、水煤氣、半水煤氣、空氣煤氣、焦爐氣、變換氣、CO2再生氣、食品CO2、鋼廠原料氣、沼氣、石油化工等各種氣體的精脫H2S，也可與水解504催化劑配套使用達到H2S+CO2≤0.06ppm,彌補活性炭精脫硫劑的不足，使氧化鐵脫硫劑新工藝應用更為廣泛。

      1、裝填

    脫硫劑裝填好壞直接影響使用效果，必須引起足夠重視，整個脫硫劑裝填過程應有專人負責，并注意以下幾點：

   （1）在脫硫塔的格蓖板上先鋪設二層網孔小于為8－10目的不銹鋼網。

   （2）在鐵絲網上再鋪設一層20－30mm, Φ20－30mm厚的碎焦塊。

   （3）由于運輸、裝卸過程中會產生粉塵，裝填前需要過篩。

   （4）使用專門的裝填工具，卸料管應能自由轉動，使料能均勻裝填反應器四周，嚴禁從中間倒入脫硫劑，防止裝填不勻。

   （5）脫硫劑在使用過程中隨吸硫量的增大而強度遞增，故在脫硫塔中應分層裝填。每層按脫硫劑裝填高度劃線，保證裝足、裝平、裝勻。

   （6）裝填過程中，嚴格禁止直接踩踏硫劑，可將木板墊在料層上，再進入扒料和檢查裝填情況。

   （7）脫硫原料氣入口處，應裝上格蓖板或碎焦塊，以防止吹散脫硫劑。

    2、使用

   （1）脫硫塔一般不必專門加熱而耗能，但在室外的脫硫裝置冬季必須保溫，以免氣體過冷，降低脫硫劑活性和床層上積水而惡化操作。

   （2）脫硫前應設法除去焦油和水沬。

   （3）脫硫劑可一次全部更換，也可按氣流方向逐段更換。

   （4）定時排放脫硫塔前水分離器和脫硫塔底部積水，嚴禁氣體帶液進入脫硫塔。

   （5）操作要穩定、使用要合理，以發揮其優良性能。

     3、運輸

   （1）脫硫劑在運輸時要輕裝輕放、避免震動和碰撞，以免破損。

   （2）脫硫劑在保管期間，要防止吸嘲及化學污染。

赤峰市福悅活性炭廠

          地     址：內蒙古赤峰寧城縣天義鎮富家窩鋪村（原糖廠南側）

     經     理：李果
     手     機：15047259045

     Q       Q：3271344781
     郵     箱：3271344781@qq.com
     網     址：https://shop1438707253312.

Product introduction
Iron oxide desulfurization agent is the main active component of iron oxide, adding other accelerators to the processing of high efficiency gas purification agent. In between 20 to 100 degrees Celsius, the hydrogen sulfide has a high removal performance, the thiol organic sulfur and most of the nitrogen oxides also have a certain removal effect. Iron oxide desulfurization agent is the active Fe2O3 as the main component, and add a variety of additives made. Is a new type of high efficient dry gas desulfurization agent, which can work under normal temperature and pressure condition. The hydrogen sulfide has very high removal performance, and it also has a certain effect on the removal of the thiol organic sulfur and most of the nitrogen oxides.
Iron oxide desulfurization agent because of its sulfur capacity, low price, can be at room temperature (20 degrees Celsius to 100 degrees Celsius) under the air regeneration and so on and so on by the user welcome. The device has the advantages of simple equipment, convenient operation, high sulfur capacity, high purification degree and strong adaptability.
Performance characteristics
Iron oxide desulfurization agent because of its high sulfur content, low price, can be recycled at room temperature and so on, and is welcomed by users. But there are also poor strength, meet, desulfurization gouache precision (1ppm) and other shortcomings, affecting its industrial application.
In view of the above situation, our company technical personnel after several years of painstaking research, developed a series of HYF new type of iron oxide desulfurization agent, which is characterized by:
1, high desulfurization accuracy: imported H2SI1000ppm, the export of 0.05ppm H2S, than the average Fe2O3 of the desulfurization accuracy (1ppm) 20 times higher;
2, fast response: the use of 1000-20000h-1 Fe2O3 to be higher than ordinary airspeed 3 - 6 times.
3, work (through) sulfur capacity: under the conditions of 1 and 2, a one-time fine removal of H2S sulfur content of O2 is 20% - 3, 15 - 6 times the average Fe2O3 desulfurization agent.
4, good strength, good water resistance. Boiled 2H or soak for 30 days without powder, strength unchanged.
5, suitable for a wide range of temperature, 90 - 5
6, can be used in the absence of O2 or high CO2 conditions. H2S sulfur content 12 - 15%.
The application of desulfurization of natural gas, water gas and semi water gas, air gas, coke oven gas, gas, and CO2 transform anger, food CO2, steel raw material gas, methane gas, petrochemical and other gases finishing off H2S, and can also be matched with 504 H2S+CO2 hydrolysis catalyst reaches more than 0.06PPM, compensate for the lack of active carbon desulfurization the agent, so that the iron oxide desulfurizer new technology has been widely used.
Packing method
1, loading
Desulfurization agent loading directly affects the use effect, must cause enough attention, the whole process should be responsible for the desulfurization agent loading process, and pay attention to the following points:
(1) in the lattice grate desulfurization tower first laying two layers of mesh is less than 8 - 10 to the stainless steel mesh.
(2) a layer of 20 30mm and then laying on the barbed wire, with the diameter of 20 30mm thick pieces of coke.
(3) due to the transport, loading and unloading process will produce dust, loading before the need to sift.
(4) the use of special loading tools, discharge pipe should be free to rotate, so that the material can be evenly filled around the reactor, it is strictly prohibited from the middle of the desulfurization agent into the.
(5) in the process of using the desulfurization agent with the increase of the amount of sulfur absorption and strength increasing, so in the desulfurization tower should be layered loading. Each layer is filled with a high degree of desulfurization agent, to ensure adequate loading, leveling and loading.
(6) in the loading process, strictly prohibit the direct trample of sulfur agent, the board can be on the material layer, and then enter the grill and check the loading situation.
(7) the raw gas desulfurization entrance should be installed on the grid grate or broken pieces of coke, to prevent blow desulfurizing agent.
2, the use of
(1) the desulfurization tower generally does not need special heating and energy consumption, but in the outdoor desulfurization unit must be insulated in winter, so as to avoid gas too cold, reduce the activity of the desulfurization agent and the deterioration of water on the bed.
(2) should be removed before desulfurization of tar and water droplets.
(3) the desulfurization agent can be replaced at one time, and can be replaced by the air flow direction.
(4) the water separator and the bottom of the desulfurization tower are in a regular discharge of the desulfurization tower, and the liquid gas is strictly prohibited to enter the desulfurization tower.
(5) operation to be stable, the use of reasonable, in order to play its excellent performance.
3, transport
(1) desulfurizer during transportation to avoid collision and vibration light light, so as to avoid damage.
(2) desulfurization agent in the custody period, to prevent pollution and chemical absorption at.
